Tesoma Textile Dryer Drylight

Product Description

Performance features

Electric or gas operated.

Hot air or hot air / infrared combination.

Optionally as single or split belt version, also withreverse motion of belt directions; each separately controllable.

High air volume with filtering via easily exchangeable metalfilter.

Optimum drying results due to stepless adjustabletemperature up to 180 °C.

Simple operation with innovative Smart Control touch panel,possibility for recipe management.

Quick maintenance through hood opening within seconds withgas spring support.

Application areas

Highest demands on the production capacity.

Use on large screen-printing carousels and digital printers.

Large quantities.

Customer specific dryer design according to modularconstruction.

Great versatility – drying of different materials.

Technicaldetails of DRYLIGHT continuous dryer

Belt width: 1,700 mm, other belt widths on request

Module types: Hot air stepless adjustable up to 180 °Cstepless adjustable, combination hot air / infrared possible, cooling modulepossible

Heating: electrically heated or gas heated (natural gasor liquid gas), in addition with infrared emitters

Throughput height: 120 mm

Transport system: Teflon coated glass fibre belt, meshsize 4 mm x 4 mm, as single or split belt version, separately controllable,also in reverse directions

Belt speed: stepless adjustable from 1 – 10 m/min

Working height: 900 mm +/- 25 mm

Control: Innovative Smart Control with touch panel

Electrical connection: 400 V, 3/N/PE, 50 Hz, optionalother versions available on request.
