RapidTag LP2 Label Screen Printing Machine

The LP2 Rapid Tag is the extension of our 1 color printer to print tagless size labels on textile garments. Now with the LP2 Rapid Tag, we have the possibility to print 2 colors. Enormously fast and again with different printing plate extensions.Also, our 2 color hat and cap printer is based on this LP2 screen printing machine.

KEY FEATURES

1. Parts Counter
2. Stroke adjustment
3. Micro Registration
4. Index Speed Set up
5. Stepper Motor Indexer
6. Adjustable stroke length
7. Squeegee Angle Adjustment
8. Parts Sensor (no product no print)
9. Adjustable Stroke and flood speed
10. Print Accuracy of .001" / 0.02mm
11. High-Density Flash Cure Units
12. Pneumatic Screen Locks
13. Color Touch Screen
14. Curing Time Set up
15. Hoodie arms
16. Dwell set up

SPECIFICATION

Height: 55" /140cm

Diameter: 38" /97cm

8x Stations

2x Print Heads

3x High-Density Flash Cure Units

Print/Flash/Print/Flash/Flash

Standard Pallet Size 4"Wide x 8 "Long / 10 cm x 20 cm

Max Image Print Area 6"Wide x 6" Long /15 cm x 15 cm

Standard Frame Size 9" x 14" / 22.8 cm x 35.5 cm

Flash cure size: 5" x 5"/ 12.7cm x 12.7cm

REQUIREMENTS

AIR                                          POWER

Clean Dry Air                           220 Volt
90-110 PSI                              Single Phase

1.1 CFM                                  25 Amps
6-8 Bar
30 L/min
