Technical Specifications:

Machine size:

SB Screen width 1000-3000 mm

SL Screen Length 1600-2400 mm

Frame profile thickness 20-55 mm

Size:

Width 1600 mm

Depth SL + 240 mm

Height SH+590 mm

Energy Supply:

Voltage 3x400 + N +PE

Frequency 50 Hz

Permanent sound pressure level : Less than 70 dB(A)

Particular features

1. Vertical drying of wet or coated screens
2. Optimal drying of coated screens
3. Rugged construction of anodized aluminium profiles
4. Compact construction method
5. Bi-parting doors with transparent acrylic glass
6. Thanks to its modular design, this drying cabinet offers flexible adaptation to various on-site situations
7. Continuous adjustment of the heating temperature by means of digital temperature regulator
8. Digital temperature display (reference/actual values)
9. Can be disassembled to facilitate transportation and on-site installation
10. Temperature: Continuously adjustable up to max. 45 degree C (at room temperature of 20 Degree C)
