ATMAOE MF88 Fully Automatic CCD Registering Screen Printer

ATMAOE MF88 Fully Automatic CCD Registering Screen Printer

Product Details:

X

Product Description

Characteristic:

High accuracy of vacuum table flatness.

Appropriate vacuum hole diameter can be made depending on substrate thickness need.

CCD visual auto registering.

Three sets of servo motor are equipped for vacuum table,collocated with CCD camera displacement function.

The printing head is driven by guide rail cylinder, onto equalizing air pressure can be presented completely on printing.

Optional cleaning roller can be selected to pick up dust or particles rapidly.

Anti-static to eliminate electrostatic on substrate for smooth printing.

Enclosure keeps printing section clean, overall collocation to raise yield rate of efficient printing massive production.



Features

Four-post air locking: equipped with unique four-post airlocking function (during printing), assure printing stroke and table parallel positioning to raise printing accuracy.

Upgraded Precision: three sets of servo motor are equipped to control X-X-Y axis direction, by way of visual system to judge table displacement amount Sliding table reciprocates right / left positioning, hydraulic buffer +magnetic suction is adopted to obtain accuracy within 5 micro m

Printing layer uniform thickness: guide rail cylinder is equipped for squeegee / flood coater to raise precise linear motion, leading precise, smooth to make equalizing air pressure to present completely printing on substrate, assure printing layer uniform thickness and consistency.

Servo motor direct driven: low malfunction, solid printing torque, complete digital control, full stroke extreme stable speed motion.

Equalizing control: squeegee / flood coater with digital equalizer system control, air pressure can be preset (3-62 kgf) on touchscreen.

Safety Protection: error diagnosis, error indication, monokey auto safety restoration loop, safety light barrier, E-stop switch, warning lamp and so on comprehensive safety protection.


Specification

Model

ATMAOE-MF88

Table Size

950x950mm

Substrate Thickness

0.05-6.0mm

Max Printing Area

800x800mm

Min Printing Area

400x400mm

Productivity

400 P/H

Max Frame O/D Size

1300x1300mm

Min Frame O/D Size

1050x1020mm

Frame Height

25-45mm

Power Consumption

4.6KW

Air Exhaustion

170L/min

Machine Dimension

3060x1860x1910mm

Machine Weight

2200kg
