ATMAOE 710 Opto-Electric Screen Printer

ATMAOE 710 Opto-Electric Screen Printer

Product Details:

X

Product Description

  • Sliding table in / out traveling fast and precise, wide space operation for convenient manual loading and alignment.
  • Diverse facilitation structure for smooth setup and adjustment to raise efficiency HMI setting to save and retrieve 100 groups memory of printing parameter, exquisite setting versatile operational function and parameter to attain digital control printing quality.

  • Equipped with air locking screen micro-adjustment, screen frame and frame holding arm, quick loading / unloading screen as well as positioning, FRL unit is equipped with auto air pressure inductor, machine will stop automatically with warning upon insufficient air pressure to ensure all printing to get done with sufficient air pressure.

  • Guide rail is supported and protected by high strength Aluminium extrusion, mounting surface is machined precisely to assure parallel leveling.

  • Equipped with retractable safety bar, E-stop, auto error diagnosis system, screen cleaning protection.

  • Option: CCD camera system, dripless squeegee, anti-static bar, cleaning roller, Gripper take off with elevating conveyor.

  • Technical Specifications:





    Model

    ATMAOE-710

    ATMACE 67

    Table Size

    950 x 1250 mm

    800 x 900 mm

    Substrate Thickness

    0.1-30 mm
    (gripper 0.1-6.0 mm)

    0.1-30 mm
    (gripper 0.1-6.0 mm)

    Max Printing Area

    760 x 1060 mm

    600 x 740 mm

    Min Printing Area

    700 x 800 mm

    400 x 540 mm

    Max Productivity

    510 P/H
    (non-stop full speed full stroke)

    540 P/H
    (non-stop full stroke full speed)

    Max Frame O/D Size

    1200 x 1400 mm

    1100 x 1100 mm

    Min Frame O/D Size

    1000 x 1200 mm

    900 x 900 mm

    Frame Height

    25-45mm

    25-45mm

    Power Consumption

    4.1 KW

    4.1 KW

    Air Exhaustion

    2.8 L/cycle

    2.8 L/cycle

    Machine Dimension

    1950 x 2700 x 1450 mm

    1650 x 2420 x 1450 mm

    Machine Weight

    1155kg

    1120 kg
