ATMA AT-68C High Speed Clamshell Screen Printer

ATMA AT-68C High Speed Clamshell Screen Printer

Product Details:

X

Product Description

  • Rapid Up Down : incorporated electric and pneumatic optimal transmission mode, special balance loading, rapid and stable up down motion and precise positioning.

  • Electromagnetic Suction Positioning : screen tilt lowering to margin limitation position to be locked by electromagnetic fixation against heavy printing pressure.

  • Precise Positioning: German gear motor + swivel arm drive up down, rapid stable and silent motion, precise positioning to afford long term operation.

  • Peel-off Function: guided rail cylinder drives peel-off device to avoid phenomenon of sticky screen mesh after printing.

  • Vacuum Device : equipped with strong vacuum motor, adjustable suction power high or low depending on substrate requirement.

  • Digital Control : adopt HMI digital control, enable to preset versatile function and operational parameters.
  • Standardized Management : 100 groups of memory module can be named and numbered individually, quick save and retrieve to facilitate standardized management of each different production process.

  • Safety Protection : equipped with E-stop safety bar, safety press bar switch, safety ascent cylinder, it is triggered during screen descent, screen structure automatically lifts up slowly to original position and release loading weight, comprehensive protection ensure operator safety.

Technical Specifications:





Model

AT-68C

Substrate Thickness

0.1-25mm

Productivity

720 P/H

Max Printing Area

600x800mm

Min Printing Area

300x300mm

Max Frame O/D Size

1000x1000mm

Min Frame O/D Size

800x800mm

Air Exhaustion

22 L/min

Power Consumption

2.75kw

Machine Dimension

1580x1120x1400mm

Machine Weight

660kg
