ATMA AT-60PPD Digital Electric Sliding Table Screen Printer

ATMA AT-60PPD Digital Electric Sliding Table Screen Printer

Product Details:

X

Product Description

  1. Innovative Design : motorized screen vertical updown design (patented), fast stable silent motion.
  2. Aluminum Extruded Module : Aluminum alloy extrusion formation structure, high strength and lightweight, raise durability and precision to support extreme heavy loading.
  3. Convenient Adjustment : active cantilever arm is used for screen frame holder design, lightweight and robust structure,facilitate movement and adjusting.
  4. Digital Control : PLC programmable control,versatile function and quick operation.
  5. Easy Operation : adopt HMI touch screen to display Chinese and English language, digitalized control able to achieve quick selection and setting.
  6. Error Display : LCD screen automatic display error, explicitly indicate quick troubleshooting.
  7. Comprehensive Protection : equipped E-stop switch,safety bar, safety press plate and auto restoration stroke start point, protect operator safety, reduce defective rate.
  8. Option : pneumatic registration pin / pup-up pin,drip-less squeegee.


Technical Specifications:



Model

AT-60PPD

Substrate Thickness

0-120 mm

Productivity

600 P/H

Max Printing Area

400 x 600 mm

Max Frame O/D Size

600 x 950 mm

Table Size

500 x 700 mm

Power Consumption

1.54 KW

Air Exhaustion

3.7 L/cycle

Machine Weight

580 kg

Machine Dimension

1320 x 1520 x 1780 mm
